    Digital Air Permeability GB/T 5453 Protective Clothing Testing Equipment

    Protective Clothing Tester Digital Air Permeability Testing Machine

    Product Introduction

    Application:

    Digital Air Permeability Testing Machine To test the air permeability of various woven fabrics, knitted fabrics, non-woven fabrics, industrial filter materials and protective clothing etc.

    Standards:

    GB/T 5453, GB/T 13764, ISO 9237, ISO 7231, ISO 5636, BS 5636, ASTM D737, DIN 53887, JISL1096, AFNORG 07-111, EDANA140.1,ISO 9073-15

    Feature

    1.High precision import pressure and pressure differential sensor to ensuring the accuracy of data.
    2.Microcomputer processing without manual calculation and the test result can displayed directly.
    3.Digital Air Permeability Tester Equipped with thermal printer to print the experiment result.
    4.Built-in 7 testing units: mm/s,m3/m2.min,cm3/cm2.s,m3/m2.h, cfm, L/dm2.min, L/m2.s.
    5.Touch Screen Control as well as operating by connect to the computer.
    6.Testing arm was pneumatic controlled and can press and put up automatically.
    7.Digital Air Permeability Tester Equipped with 11 nozzle with different calibers to meet different specimens.
    8.Change the nozzle manually.

    Key Specifications

    Operation display

    Touch screen

    Nozzle pressure difference

    4,000Pa

    Specimen pressure difference

    1,000Pa

    Permeability range

    0.112000mm/s

    Measuring error

    ≤±2

    Measuring unit

    mm/s, cfm, cm3/cm2/s, I/m2/s, I/dm2/min, m3/m2/min

    Testing area

    5cm2, 20cm2, 50cm2, 100cm2 ,

    Ф50mm (≈19.6cm2), Ф70mm(≈38.3cm2)

    Fabric thickness

    ≤12mm

    Nozzle parameter

    Number

    0

    1

    2

    3

    4

    5

    6

    7

    8

    9

    Dia. mm

    0.8

    1.2

    2

    3

    4

    6

    8

    10

    12

    16

    Power supply

    AC 220V 50/60HZ, 2KW

    Dimensions

    700 x 520 x 1100mm (L x W x H)

    Weight

    93kg
