    strong load capacity 300rpm ISTA Transportation Vibration Tester

    Ask Lasest Price
    Brand Name : GESTER
    Model Number : GT-M11
    Certification : CE, ISO
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200 set/month
    Delivery Time : 10-30 days
    Price : Best price,reasonable
    • Product Details
    • Company Profile

    strong load capacity 300rpm ISTA Transportation Vibration Tester

    ISTA Test Transportation Simulation Vibration Tester


    Product Introduction

    Application:


    The Transportation Vibration Tester is to simulate the goods in transit, encounter different road conditions such as bumpy, uphill, downhill, cornering, etc., products in the car produce the collision between goods and goods or goods and car and the extrusion between goods and goods, etc., causing damage to the products, so that the quality of goods and goods packaging can be further improved. Mainly used for vibration test of toys, electronics, furniture, gifts, ceramics, communications, equipment, computers and car parts.


    Standards:

    ISTA

    ASTM D999



    Feature

    1. Have buffer start function, work medium noise very low.

    2. Digital meter shows the vibration frequency

    3. Synchronization silencing belt transmission

    4. The sample clamping adopts guide rail type, easy to operate and safe

    5. The machine base adopts heavy channel steel with vibration damping pads, easy to install, operate steadily, no need to install foot screws

    6. Dc motor speed regulation, smooth operation, strong load capacity

    7. Rotary vibration (commonly known as monkey type), Accord with standard of Europe and the United States transportation


    Key Specifications

    Model

    GT-M11

    Vibration frequency

    100-300rpm

    Frequency precision

    2rpm

    Max load capacity

    100kg

    Displacement (Vibration amplitude range)

    25.4mm (1 inch)

    Vibration mode

    Reciprocating (Rotary)

    Simulation vehicle speed

    25~40km/h

    Standard motions

    Rotary DC Motion (Standard)

    Standard table Size

    1000x1100mm

    Timing functions

    99H99M

    Power supply

    AC 220V 50/60Hz

    Dimensions

    125x110x60 (L x W x H)

    Weight

    155kg

    Standards

    ISTA; ASTM D999
